Technische Dokumentation
-
Technisches Datenblatt
CORRENTI BORDER
| ART.-NR. | Beschreibung | d₁
[mm]
|
L
[mm]
|
Stk. |
|---|---|---|---|---|
| BORBAR45 | tapered handrail | 45 | 3000 | 1 |
| BORBAR32 | tapered intermediate rail | 32 | 3000 | 1 |
| BORBAR45F | non-tapered handrail for folding railing | 45 | 3000 | 1 |
| BORBAR32F | non-tapered intermediate rail for folding railing | 32 | 3000 | 1 |
| BORBAR45R | tapered and reinforced handrail | 45 | 3000 | 1 |
MONTANTI BORDER W
| ART.-NR. | Beschreibung | H
[mm]
|
Stk. |
|---|---|---|---|
| BORUP100 | straight upright | 1005 | 1 |
| BORUP110 | straight upright | 1105 | 1 |
| BORUP100F | folding upright | 1005 | 1 |
| BORUP100R | reinforced straight upright for EN 13374 and BS 13700 | 1005 | 1 |
| BORUP110F | folding upright | 1105 | 1 |
| BORUP110R | reinforced straight upright for EN 13374 and BS 13700 | 1105 | 1 |
| BORUP113C | 15° curved upright | 1125 | 1 |
TAVOLE FERMAPIEDE
| ART.-NR. | Beschreibung | H
[mm]
|
B
[mm]
|
Stk. |
|---|---|---|---|---|
| BORTB | toe board | 150 | 3000 | 1 |
| BORTBJUN | connector for straight and curved joint for toe board | 24 | 100 | 1 |
| BORTBCAP | end cap for toe board | 150 | 26 | 1 |
BASI BORDER W
| ART.-NR. | Material | B
[mm]
|
H
[mm]
|
L
[mm]
|
Stk. |
|---|---|---|---|---|---|
| BORBASEW | EN AW 6005A-T6 | 1400 | 115 | 100 | 1 |
| BORBASEWFCR | EN AW 6005A-T6 | 1400 | 115 | 100 | 1 |
| BORBASEWFCL | EN AW 6005A-T6 | 1400 | 115 | 100 | 1 |
ZAVORRE BORDER W
| ART.-NR. | Material | B
[mm]
|
H
[mm]
|
L
[mm]
|
Stk. |
|---|---|---|---|---|---|
| BORWT | PP | 265 | 50 | 400 | 1 |
| BORWTBOX | PP | 265 | 50 | 400 | 1 |
| BORWTFRAME | EN AW 6060-T6 | 570 | 80 | 530 | 1 |
GATE BORDER
| ART.-NR. | Material | B
[mm]
|
H
[mm]
|
L
[mm]
|
Stk. |
|---|---|---|---|---|---|
| BORGATE600 | EN AW 6060-T6 | - | 630 | 600 | 1 |
ACCESSORI BORDER
| ART.-NR. | Beschreibung | Stk. | |
|---|---|---|---|
| BORCAP | plastic cap for slotted upright Ø45mm | 1 | |
| BORCAP32 | plastic cap for intermediate rail Ø32mm | 1 | |
| BORCAP45 | plastic cap for handrail Ø45mm | 1 | |
| BORCOR | universal bracket for handrail and rails | 1 | |
| BORWALL | universal wall-mounted end element for handrail and rails | 1 | |
| MMS5525A2 |
New
|
self-tapping screw A2 Ø5,5x25mm | 50 |
